conveyor belt
Power plant, Cement and power supply
Conveying materials : Lime Stone, Rock Quarry, Coal and others
• Depending on the application, textile conveyor belts feature various cover stock properties and a single- or multi-ply textile tensile member.
• Steel plant
• Cement plant
• Thermoelectric power plant
• Re-cycling company
Total strength
(kN/m)
Belt width
(mm)
Ply
Top cover Thickness
(mm)
Bottom cover Thickness
(mm)
315
400~600
3
3.2~4.8
1.6~2.4
400
400~900
3~4
3.2~4.8
1.6~2.4
500
400~1200
3~5
3.2~4.8
1.6~3.2
630
500~1600
3~5
3.2~6.4
1.6~3.2
800
750~1600
4~5
4.8~8.0
2.4~3.2
1000
750~2200
4~6
4.8~8.0
2.4~3.2
1250
750~2200
5~6
4.8~8.0
2.4~3.2
1500
750~2200
5~6
4.8~8.0
2.4~3.2
